DIMENSION BLUE MONGER (OC-DBMn)

Features
A completely new type of effect that blurs the lines between the Flanger effect and Chorus effect. Allows guitarists to create a “watery”, 3-dimensional modulation effect that gives your tone a sense of transparency and rich reverberation.


Bjorn's Description
The DIMENSION BLUE MONGER is a modulation pedal tuned like a flanger in terms of delay time. However, without feedback, the DIMENSION BLUE MONGER creates a chorus type sound that can be set to make up five choruses in parallel. This causes a diffusion and complex chorus sound while maintaining the incredible clarity of every single note.

COMPLEXITY: Adjust modulation speed and depth with one knob. At counter-clockwise position, produce a standard chorus sound. At the most clockwise position, the modulation becomes bolder and more complex.
COLOUR: Adjust overall brightness of the tone.
MIX: Adjust dry/wet balance of the overall effect. Choose between a predominant effect or an effect that appears only at the tails of phrases.

The Chorus effect is achieved by mixing dry signal with delays and modulation. The result is a number of peaks and notches which move slightly up and down the frequency spectrum, a pattern similar to water ripples.

- Bjorn Juhl

Specifications
Input impedance: 280 K
Output impedance: 2K
Drive voltage: 9 V
Current consumption: 27mA
S / N ratio: -90 dB
Size: 39 W x 100 D x 31 H mm (not including projections)
　　 47 W x 100 D x 48 H mm (including projections)
Weight: Approximately 160 g
True-Bypass Switching
High Quality Aluminum Enclosure
Power: 9V Battery or Standard DC Power Supply

DIMENSION BLUE MONGER Manual.pdf

Promotional Pictures (for dealers)
2000pix×2000pix 350dpi
